Twitter| Business Type | Manufacturer, Exporter, Supplier |
| Temperature Range | 0 to 750 deg C |
| Accuracy | +/-1.5 deg C or +/-0.4%) |
| Class | Class 1 |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Probe Material
Stainless Steel
Application
Industrial Process Control
Assembly
Surface Thermocouple
Mount
Bayonet
Probe Termination
Lead Wire
Probe Diameter
0.5 - 8 mm
Probe Length
151 - 300 mm
Junction Type
Ungrounded
Configuration
Simplex
Material Grade
SS304
Insulation
FG/FG/SS
J-Type Thermocouple Sensor
A J-type thermocouple sensor is a type of temperature measurement device that utilizes two different metal wires to generate a voltage that corresponds to temperature. Specifically, it consists of an iron wire and a constantan (copper-nickel alloy) wire. J-type thermocouples are known for their reliability and accuracy in various applications, particularly in environments where temperatures range from low to moderately high.
Preetemp Technologies has inhouse manufacturing facilities for manufacturing of J Type Thermocouples as per customers design and specifications.
Looking for "Thermocouple J Type Sensor" ?
